PL-1 THERMOSTAT

An Affordable, Easy-to-Use Temperature Controller

The PL-1 is an economical, easy-to-use wire-less tank thermostat specifically designed for use in wineries and breweries. Housed in a durable water-tight enclosure, the PL-1 offers stand-alone temperature control and the industry’s easiest networking for mobile access, control, fermentation tracking and alarm notifications.

Networking PL-1 thermostats requires NO NEW WIRES at the tank. Instead, this innovative controller uses advanced power line signaling technology to reliably and securely communicate over existing electrical wires in the cellar.

By eliminating network cabling at the tank, the PL-1 dramatically reduces installation costs and enables wineries and breweries alike to easily network their controls to TankNET® fermentation management software.

Features

  • Wire-less Networking
  • Two Temperature Probe Inputs
  • Cool, Heat and Auto Control
  • IP-67 Rated

Specifications
INPUT VOLTAGE 120VAC 50/60Hz at 0.05A
24VAC 50/60Hz at 0.20A
RELAY CONTACTS: Cool Relay: Form-C, 5A at 120VAC
Heat Relay: Form-C, 5A at 120VAC
PROBE INPUTS: Input 1: Calibration-Free Temperature Probe
Input 2: Temperature Probe or 4-20mA Sensor
OPERATING TEMPERATURE: 0 to 50 ºC
ENCLOSURE: Polycarbonate, UL50, NEMA-4X Rated
SAFETY RATING: ETL LISTED
Ordering Information
6000-024 24VAC 50/60Hz
6000-120 120VAC 50/60Hz
